LPSD Asymmetric Polyethersulfone (PES) Membrane Filter Cartridge
Price varies depending on material, logo, quantity and customization requirements.
Introduction
-
★ LPSD Polyethersulfone (PES) Filter Cartridge is made from Chinese / German asymmetric PES membrane. The asymmetric membrane structure allows gradient filter rating and high dirt holding capacity.
★ The protein binding, solvable and extractable of the LPSD membrane is extremely low. It is widely used in sterilization and filtration of liquids such as buffers, culture media, blood products, eye drops, large and small infusions, ultra-pure water, food and beverages, etc.
★ The filter cartridges are 100% with integrity test before delivery and it can be traced.
LPSD-J model has double layers PES membrane. It can meet more stringent filtration requirements.Structure & Material
Filtration layer: asymmetric PES membrane (PES)
Double layer PES membrane (Double PES)
Support/ Diversion layer: Polypropylene (PP)
Inner core: Polypropylene (PP)
Cage/ End Fitting: Polypropylene (PP)
Specification
Outer diameter: 68 mm
Inner diameter: 33 mm
Length: 5 to 40 inch
Filtration area: >0.65 m2/ 10 inch
Adapter: 222, 226, DOE, Thread (customized)
Operating Condition
Continuous working temperature: <60 ℃
Max differential pressure (Normal flow): 0.51 MPa@25℃, 0.19 MPa@80℃
Max differential pressure(Reverse flow ): 0.21 MPa@25℃
Sterilization: 121℃/ 30 min steam
Application
Microelectronics ultra-pure water
Pharmaceutical process water
Microbial fermentation
Wine & beer
Acid, base and oxidizing agent
Model Filter Rating End Fitting Length Sealing Application Code LPSD LPSD-J 0003=0.03um 0045=0.45um A=DOE flat 05=5inch S=Silicone CE=Chemical 0010=0.1um 0065=0.65um B=222 flat 10=10inch E=EPDM ME=Microelectronics 0022=0.22um C=222 fin 20=20inch V=FKM BM=Pharmaceutical 010=0.1+0.1um D=226 flat 30=30inch P=FEP encapsulated FB=Food & beverage 022=0.22+0.22um E=226 fin 40=40inch F=PTFE 045=0.45+0.45um M=Thread
