LDPG Polytetrafluoroethylene (PTFE) Filter Cartridge
Price varies depending on material, logo, quantity and customization requirements.
Introduction
-
★ LDPG PTFE filter cartridge is made from hydrophobic PTFE membrane. It is suitable for high flow velocity, low pressure drop and GMP standard gas sterilization applications.
★ It can 100% filtrate the particles larger than 0.02 micron, including phage, bacteria and other solids.
Structure & Material
Filtration layer: Hydrophobic PTFE membrane
Support/ Guide layer: Polypropylene
Inner core: Polypropylene / SS316L
Cage/ End Fitting: Polypropylene
Specification
Outer diameter: 68 mm
Inner diameter: 33 mm
Length: 5 to 40 inch
Filtration area: >1.0 m2/ 10 inch
Adapter: 222, 226, DOE, Thread (customized)
Operating Condition
Continuous working temperature: <60 ℃
Sterilization: 121℃/ 30 min steam
Application
Sterilization for compressed air, nitrogen, carbon dioxide
Tank breather, fermentation tank sterilization
Ordering Information
Model Filter Rating End Fitting Length Sealing Application Code LDPG 00H3=0.003um A=DOE flat 05=5inch S=Silicone CE=Chemical 0001=0.01um B=222 flat 10=10inch E=EPDM ME=Microelectronics 0005=0.05um C=222 fin 20=20inch V=FKM BM=Pharmaceutical 0010=0.1um D=226 flat 30=30inch P=FEP encapsulated FB=Food & beverage 0050=0.5um E=226 fin 40=40inch F=PTFE M=Thread
