DP-02 High-precision Polypropylene Filter Cartridge
Price varies depending on material, logo, quantity and customization requirements.
Introduction
-
★ DP-02 high-precision polypropylene (PP) filter cartridge is made of multi-layer gradient rating PP membrane. It is the upgrade of DP-01. Thanks to the complex and 3D indepth structure of the nanofiber, this model gains almost absolute filtration rating and high dirty holding capacity.
★ This absolute rating PP filter cartridge can reach above 99.7% retention rate at certain filter rating.
★ DP-03 is cleaned by 18 megohm ultra-pure water and vacuum dried before delivery. It has enhanced cleanness and reduced the fiber mitigation risk. It can be ready-to-use on the customer’s site and is widely used in precision filtration in ultra clean fields.
Specification
Outer diameter: 68 mm
Inner diameter: 33 mm
Length: 5 to 40 inch
Filtration area: 0.52 to 0.71 m2/ 10 inch
Adapter: 222, 226, DOE, Thread (customized)
Operating Condition
Continuous working temperature: <80 ℃
Max differential pressure (Normal flow): 0.41 MPa@25℃, 0.23 MPa@80℃
Max differential pressure(Reverse flow ): 0.21 MPa@25℃
Sterilization: 121℃/ 30 min steam
Structure & Material
Filtration layer: High rating PP membrane
Support/ Division layer: Polypropylene
Inner core: PP/ SS316L
Cage: Polypropylene
End Fitting: PP / PP + liner
Application
Process water precision filtration
Pharmaceutical sterilized water
Semi-conductor ultra-pure water
Ordering Information
Model Filter Rating End Fitting Length Sealing Application Code DP-02
DP-030010=0.1um 0200=2um A=DOE flat 05=5inch S=Silicone CE=Chemical 0020=0.2um 0500=5um B=222 flat 10=10inch E=EPDM ME=Microelectronics 0045=0.45um 1000=10um C=222 fin 20=20inch V=FKM BM=Pharmaceutical 0080=0.8um D=226 flat 30=30inch P=FEP encapsulated FB=Food & beverage 0100=1um E=226 fin 40=40inch F=PTFE M=Thread
